“Space Poop Challenge”

June 12, 2017

One of the harsh realities of life in space is that in an emergency, astronauts may have to live in their spacesuits for days on end. If that ever does happen, how will they go to the bathroom? That’s the question NASA hopes to answer. (This story is a sneak peek from our 30th annual edition, Uncle John’s Old Faithful Bathroom Reader, available November 2017.)

National Astronaut Day

WHEN YOU GOTTA GO…

There are three situations during a typical mission to the International Space Station in which the astronauts may not have access to a bathroom when they need one: 1) on their way to the space station at the start of the mission; 2) on their way back to Earth at the end of the mission; and 3) during spacewalks, when they are outside the station and can’t get back inside easily or quickly. None of these circumstances require the astronauts to go more than ten hours without access to a toilet, so the solution, while awkward, is simple: they wear diapers inside their spacesuits. And if they have to go, they go.

Even in an emergency, such as a module of the ISS being struck by a piece of space debris and losing pressure, if the astronauts had to evacuate the station they’d be back on Earth in less than a day, so once again, diapers would suffice.

But what about on a mission to Mars, when Earth will be many months away instead of only hours? If a spacecraft on its way to the Red Planet was struck by a micrometeoroid and lost pressure, the astronauts might be stuck inside their spacesuits for several days until they repaired the damage and were able to re-pressurize the spacecraft. In such a situation a single diaper, worn for days, would not be good enough.

Out-house

Ordinarily NASA tackles such challenges with in-house engineers or assigns them to a contractor, but in October 2016 it took a more novel approach. Working with a crowdsourcing website called HeroX, it launched a contest called the “Space Poop Challenge” and invited all comers to take a stab coming up with an in-suit “fecal, urine and menstrual management system” that would enable an astronaut to remain in their spacesuit for 144 hours straight. Why 144 hours? The most likely explanation is because 144 hours adds up to six days. (It’s also possible that someone at NASA has a sense of humor: 144 hours is also 12 dozen hours. What’s another word for 12 dozen? Gross!) Any solution entered in the contest would have to be simple enough for an astronaut to operate in microgravity while wearing bulky spacesuit gloves. It would also have to either store the liquid and solid waste somewhere inside the suit, or remove it entirely.

Entrants were given from October 11 until December 20, 2016 to come up with ideas and submit them to NASA. The first prize was $15,000; second prize was $10,000; and third prize was $5,000.

Ready, set, go!

When NASA gave contestants just over two months to invent something, it wasn’t sure how many people would enter. It was pleasantly surprised to receive more than 5,000 proposals from nearly 20,000 people all over the world, including many who worked in teams. After studying the entries for two months, in February 2017 it announced the winners. And they are…

Third Place: SWIMsuit Zero Gravity Underwear

Inventor: Hugo Shelley, a product designer in the UK

Details: The underwear looks a lot like a pair of spandex biking shorts with front and rear catheters attached—the external type of catheter, so they’re worn over the anatomical areas in question, not inserted into them, which would be way too uncomfortable if worn for six days straight. An electronic mechanism disinfects liquid and solid waste and pumps it into a sealable, compressible pouch on the leg of the garment.

Second Place: Air-PUSH Urinary Girdle

Inventor: Space Poop Unification of Doctors (SPUDs), a team consisting of dentist Katherine Kin, environmental engineer Stacey Louie, and physician Tony Gonzalez, all from Houston, Texas

Details: The device resembles the cup of an athletic supporter, one with two small air hoses attached at the top, and a larger hose at the bottom. Air flows through the upper hoses into the cup, blowing any urine or menstrual fluids into the larger hose at the bottom, and from there to a storage pouch inside the suit. Bonus: the airflow is generated by the astronauts themselves as they move around while wearing the spacesuit, so there are fewer mechanical parts to break.

Note: The Air-PUSH girdle does not address the issue of astronaut poop—an odd choice for an entrant in a contest called the Space Poop Challenge, but NASA judges were nonetheless impressed enough to award the team the $10,000 second prize. (They’re number two!)

First Place: MACES Perineal Access & Toileting System (M-PATS)

Inventor: Colonel Thatcher Cardon, an Air Force flight surgeon stationed at Laughlin Air Force Base in Texas

Details: The system consists of an airlock, called a “perineal access port,” installed on the crotch of the astronaut’s spacesuit, and a series of toileting “tools” that can be passed through the airlock without the spacesuit losing air pressure. Cardon drew inspiration from “keyhole” surgeries, in which complicated operations are performed by inserting narrow surgical tools through tiny incisions. “They can even replace heart valves now through catheters in an artery. So [a tiny opening] should be able to handle a little bit of poop,” he says.

Cardon was disgusted by the idea of storing six days’ worth of human waste inside a spacesuit. So unlike the other two winners, his system removes the waste from the suit for storage or disposal elsewhere.

Tools of the Trade:

  • One of Cardon’s tools is an inflatable bedpan that can be inserted through the airlock while deflated, then maneuvered into position and inflated with a squeeze bulb. A vacuum hose drains the bedpan and sucks the waste out of the spacesuit. Afterward, the bedpan is deflated and removed through the airlock.
  • If the astronaut only has to urinate, a vacuum hose with a male or female-shaped external catheters can be inserted through the airlock.
  • After an astronaut has completed their business, a bidet tool can be used to wash affected areas, and after that, a tool called a “hygiene wand” that substitutes for toilet paper can also be used. It consists of a vacuum hose covered with a bunched-up tube of terry cloth at the tip that’s used to wipe the affected area. Then when the job is finished, the soiled fabric is pulled “through the middle of the wand so that fresh fabric slides forward…in a motion similar to a sock being turned inside out,” Cardon says. The result is a wand that’s clean and ready for the next use.
  • Cardon has even devised special mens’ and womens’ underwear that can be inserted and removed through the airlock, so that astronauts can change into fresh undies without having to remove their spacesuits.

Here we go again

If you missed the Space Poop Challenge, fear not! The agency was so impressed by the entries that it’s considering doing more contests. “We enjoyed seeing the innovative approaches, given such a demanding scenario,” says engineer Kirstyn Johnson. “Others at NASA are now thinking about ways we can leverage a crowdsourcing approach to solve more of our spaceflight challenges.”
